Heat and Thermodynamics
Download Tamil Nadu 11th Standard Physics question papers, model tests, one-mark questions, important questions, and public exam papers in PDF format. Free study materials and answer keys for TN State Board students.
Questions + Answers key
Take MCQ Physics Test1.
Define molar specific heat capacity.
2.

We often have the experience of pumping air into bicycle tyre using hand pump. Consider the air inside the pump as a thermodynamic system having volume V at atmospheric pressure and room temperature, 27°C. Assume that the nozzle of the tyre is blocked and you push the pump to a volume 1/4 of V.
Calculate the final temperature of air in the pump? (For air, since the nozzle is blocked air will not flow into tyre and it can be treated as an adiabatic compression).
3.
Give an example of a quasi-static process.
4.
Eiffel tower is made up of iron and its height is roughly 300 m. During winter season (January) in France the temperature is 2°C and in hot summer its average temperature 25°C. Calculate the change in height of Eiffel tower between summer and winter. The linear thermal expansion coefficient for iron α = 10 x 10-6 per °C.

5.
a. ‘A lake has more rain’.
b. ‘A hot cup of coff ee has more heat’.
What is wrong in these two statements?
6.
What is a thermal expansion?
7.
Define specific heat capacity and give its unit.
8.
During a cyclic process, a heat engine absorbs 500 J of heat from a hot reservoir, does work and ejects an amount of heat 300 J into the surroundings (cold reservoir). Calculate the efficiency of the heat engine?
9.
An ideal refrigerator has a freezer at temperature −12°C. The coefficient of performance of the engine is 5. The temperature of the air (to which the heat ejected) is
50°C
45.2°C
40.2°C
37.5°C
10.
The efficiency of a heat engine working between the freezing point and boiling point of water is
6.25%
20%
26.8%
12.5%
11.
A distant star emits radiation with maximum intensity at 350 nm. The temperature of the star is
8280 K
5000 K
7260 K
9044 K
12.
A hot cup of coffee is kept on the table. After some time it attains a thermal equilibrium with the surroundings. By considering the air molecules in the room as a thermodynamic system, which of the following is true
ΔU > 0, Q = 0
ΔU > 0, W < 0
ΔU > 0, Q > 0
ΔU = 0, Q > 0
13.
In hot summer after a bath, the body’s
internal energy decreases
internal energy increases
heat decreases
no change in internal energy and heat
1.
Molar specific heat capacity is defined as heat energy required to increase the temperature of one mole of substance by 1 K or 10C
C = \(\frac { 1 }{ u } \left( \frac { \triangle Q }{ \triangle T } \right) \)
Here C is known as molar specific heat capacity of a substance and f. L is number of moles in the substance.
2.
Here, the process is adiabatic compression. The volume is given and temperature is to be found. we can use the equation (8.38 )
\({ T }_{ i }{ V }_{ i }^{ \Upsilon -1 }{ =T }_{ f }{ V }_{ f }^{ \Upsilon -1 }.\)
Ti = 300 K (273 + 27°C = 300 K)
\({ V }_{ i }=V\& { V }_{ f }=\frac { V }{ 4 } \)
\({ T }_{ f }={ T }_{ i }{ \left( \frac { { V }_{ i } }{ { V }_{ f } } \right) }^{ \Upsilon -1 }\) = 300 K × 41.4-1 = 300K\(\times\)1.741
T2 ≈ 522 K or 2490C
This temperature is higher than the boiling point of water. So it is very dangerous to touch the nozzle of blocked pump when you pump air.
3.
Consider a container of gas with volume V, pressure P and temperature T. If we add sand particles one by one slowly on the top of the piston, the piston will move inward very slowly. This can be taken as almost a quasi-static process. It is shown in the figure

Sand particles added slowly- quasi-static process
4.
\(\frac { \Delta L }{ L } ={ \alpha }_{ L }{ \Delta }_{ T }\)
\(\Delta L={ L\alpha }_{ L }{ \Delta }_{ T }\)
\(\Delta\)L = 10\(\times\)10-6 \(\times\)300\(\times\)23 = 0.69 m=69 mm
Area Expansion
For a small change in temperatur ΔT the fractional change in area \(\left(ΔA\over A_0\right)\) substance is directly proportional to ΔT and it can be written as
\({ΔA\over A_0}=\alpha_AΔT\)
Therefore, \(\alpha_A={ΔA\over A_0ΔT}\)
Where, αA = coefficient of area expansion.
ΔA = Change in area
A0 = Original area
ΔT = Change in temperature
Volume Expansion
For a small change in temperature ΔT the fractional change in volume \(\left(ΔV\over V_0\right)\) of a substance is directly proportional to ΔT.
\({ΔV\over V_0}=\alpha_VΔT\)
Therefore, \(\alpha_V={ΔV\over V_0ΔT}\)
Where, αV = coefficient of volume expansion.
ΔV = Change in volume
V0 = Original volume
ΔT = Change in temperature
Unit of coeffi cient of linear, area and volumetric expansion of solids is oC-1 or K-1
5.
a. When it rains, lake receives water from the cloud. Once the rain stops, the lake will have more water than before raining. Here ‘raining’ is a process which brings water from the cloud. Rain is not a quantity rather it is water in transit. So the statement ‘lake has more rain is wrong, instead the ‘lake has more water will be appropriate.
b. When heated, a cup of coffee receives heat from the stove. Once the coffee is taken from the stove, the cup of coffee has more internal energy than before. ‘Heat’ is the energy in transit and which flows from an object at higher temperature to an object at lower temperature. Heat is not a quantity. So the statement ‘A hot cup of coffee has more heat is wrong, instead ‘coffee is hot’ will be appropriate.
6.
Thermal expansion is the tendency of matter to change in shape, area, and volume due to a change in temperature.
7.
Specific heat capacity of a substance is defined as the amount of heat energy required to raise the temperature of 1 kg of a substance by 1 Kelvin or 1oC. Its unit is JKg-1 K-1.
8.
The efficiency of heat engine is given by
\(\eta =1-\frac { { Q }_{ L } }{ { Q }_{ H } } \)
\(\eta =1-\frac { 300 }{ 500 } =1-\frac { 3 }{ 5 } \)
\(\eta \) = 1 – 0.6 = 0.4
The heat engine has 40% efficiency, implying that this heat engine converts only 40% of the input heat into work.
9.
\(\mathrm{COP}=\frac{T_{L}}{T_{H}-T_{L}}\)
\(\mathrm{T}_{\mathrm{L}}=-12+273 =261 \mathrm{~K} \)
\(5=\frac{261}{T_{H}-261} \)
\(\therefore 5\left(T_{H}-261\right) =261 \)
\(5 \mathrm{~T}_{\mathrm{H}}-1305 =261 \)
\(5 \mathrm{~T}_{\mathrm{H}} =261+1305 =1566 \)
\(\therefore T_{H} =\frac{1566}{5} \)
\(=313.2 \mathrm{~K} \)
\(\mathrm{~T}_{\mathrm{H}}=313.2-273 =40.2^{\circ} \mathrm{C} \)
10.
\(\mathrm{T}_{2} =0^{\circ} \mathrm{C}+273=273 \mathrm{~K} \)
\(\mathrm{~T}_{1}=100^{\circ} \mathrm{C}=100+273=373 \mathrm{~K} \)
\(\eta =1-\frac{T_{2}}{T_{1}} \)
\(=1-\frac{273}{373} \)
\(=\frac{373-273}{373} \)
\(=\frac{100}{373}=0.26809 \times 100 \)
\(=26.809 \% \)
11.
\(\lambda_{m} T =\mathrm{b} \)
\(\therefore T =\frac{2.898 \times 10^{-3}}{350 \times 10^{-9}}\)
\(\mathrm{~T} =0.00828 \times 10^{6} \)
\(=8280 \mathrm{~K} \)
12.
During the thermal equilibrium with surroundings internal energy is increased and heat energy will be increased.
\(\Delta U>0 Q>0\)
13.
(a)
internal energy decreases
